介紹自動上料攪拌車的一些特征

所屬分類：行業動態 發布時間：2022-09-19 來源：http://842233.cn/ 瀏覽量：0

大部分人可能對于自動上料攪拌車的相關知識不太了解，自動上料攪拌車主要結構由是行走底盤、發動機、液力變矩器、前后雙驅橋、上料裝置、進料斗、卸料斗、加長卸料斗、機架、攪拌筒、攪拌專用減速機、液壓系統、電控系統、自動上水系統等組成。在這里小編就詳細的給大家介紹一下自動上料攪拌車的一些特征，具體的特征如下：

Most people may not know much about the automatic feeding mixer. The automatic feeding mixer is mainly composed of the walking chassis, engine, hydraulic torque converter, front and rear double drive axles, feeding device, feed hopper, discharge hopper, extended discharge hopper, frame, mixing cylinder, special mixer reducer, hydraulic system, electric control system, automatic water feeding system, etc. Here, I will introduce some features of the automatic feeding mixer in detail. The specific features are as follows:

1.攪拌車攪拌筒的旋轉由液壓馬達通過專用行星減速機帶動，行星減速機的輸出軸可以實現一定角度的擺動，以滿足惡劣路況下攪拌筒的跳動。

1. The rotation of the mixing drum of the mixer truck is driven by the hydraulic motor through the special planetary reducer. The output shaft of the planetary reducer can swing at a certain angle to meet the beating of the mixing drum under bad road conditions.

2.液壓系統采用恒功率變量柱塞泵，減少發動機的功率損耗。

2. The hydraulic system adopts constant power variable piston pump to reduce the power loss of the engine.

3.進水系統可根據計量設定實現自動進水。

3. The water inlet system can automatically feed water according to the metering settings.

4.干料上料，按照設計好的配比由鏟臂、動臂缸、定量的料斗自動上料。

4. The dry material is automatically fed by the shovel arm, boom cylinder and fixed hopper according to the designed proportion.

5.自動上料攪拌車攪拌筒內壁上設置雙螺旋形葉片，正向旋轉為進料、混凝土攪拌；反向旋轉，在螺旋葉片的推動下、混凝土由出料口出料。

5. Double spiral blades are set on the inner wall of the mixing drum of the automatic feeding mixer, and the positive rotation is for feeding and concrete mixing; Reverse rotation, the concrete is discharged from the outlet under the push of the spiral blade.

6.行走系統由發動機通過液力變矩器、前后傳動軸到前后橋。本發明采用前后雙橋驅動形式。采用液力變矩器減少對發動機的沖擊、延長了發動機的壽命。

6. The traveling system is from the engine to the front and rear axles through the hydraulic torque converter, front and rear transmission shafts. The invention adopts a front and rear double axle drive form. The hydraulic torque converter is used to reduce the impact on the engine and prolong the service life of the engine.

通過以上六點特征的介紹，希望能夠?qū)Υ蠹矣兴鶐椭?，如果還有不明白的地方歡迎與我們?nèi)〉寐?lián)系！

Through the introduction of the above six features, I hope it can be helpful to everyone. If there is anything you don't understand, please contact us!
